TrafiCam™ 3
Smart City Sensor
Product Variations
FLIR TrafiCam 3 is an affordable, all-round detection sensor for traffic monitoring and dynamic traffic signal control. This rugged, compact uses visual imaging and Wi-Fi technology to adapt traffic signals based on the presence detection of traffic objects vehicles while also generating basic count data at intersections and in urban environments. Key to helping traffic engineers improve vehicle flows, monitor congestion, and enhance safety, TrafiCam 3 ensures cities can collect accurate road data as well as measure travel and delay times for different transport modes.
Monitors MAC addresses of Wi-Fi-enabled devices such as smartphones to determine rates of travel along road segments.
Generates basic count data at intersections and in urban environments, in any environmental conditions.
Mounts quickly and integrates with existing platforms through BPL technology or PoE connection.
Specifications
| System Overview | |
|---|---|
| Detection Functionalities | Vehicle presence |
| Detection Zones | 8 vehicle presence zones |
| Communications | |
|---|---|
| Compression | H.264, MPEG-4, MJPEG |
| Configuration | Web page via secure Wi-Fi or Ethernet |
| Ethernet | 10/100 MBps PoE A and PoE B |
| Output | 1 N/O and 1 N/C dry contacts direct 16 N/C dry contacts via TI BPL3, TI SLT or 4 N/C via BPL3 Edge B&SIU onboard + maximum 5x N/C via 4I/O USB expansion boards (max. total 24 outputs) SDLC: BIU–64 or SUI–128 |
| WiFi | IEEE 802.11 type b,g,n EIRP <100 mW |
| Electrical | |
|---|---|
| Detection Distance | TrafiCam3 Wide: 0–25 m (0–85 ft) TrafiCam3 Narrow: 15–75 m (50–250 ft) |
| FCC | FCC part 15 class A |
| Input Power | 12 – 42 VAC 12 – 48 VDC |
| Power Consumption | Average 6.2 W, peak 7 W, peak with powerdip 14 W |
| Powerline Communication | Via TI BPL3 or TI BPL3 EDGE interface |
| Environmental | |
|---|---|
| EU Directives | EMC 2014/30/EU, RoHS 2011/65/EU |
| IP Rating | IP67 |
| Operating Temperature | -40°C to 74°C (-40°F to 165°F) |
| Shock and Vibration | NEMA TS2 specs |
| Imaging & Optical | |
|---|---|
| Frame Rate | 15 fps |
| Resolution | 640 × 480 pixel, color CMOS |
| Streaming Video | RTSP |
| Mechanical | |
|---|---|
| Bracket | PA GF30 mounting clamps and aluminum tube |
| Dimensions [incl mounting bracket] | 70 × 200 × 440 mm (2.75 × 7.87 × 17.32 in) |
| Installation Height | TrafiCam3 Wide: 3.5–6 m (11.4–19.6 ft) TrafiCam3 Narrow: 5.5–8 m (18.0–26.0 ft) |
| Material | Aluminum housing with PC GF10 sunshield; All weatherproof UV-resistant |
| Weight | 850 g / 1.87 lb (camera with bracket) |
