FLIR Quasar™ Premium Bullet AI
5 MP and 4K Ultra HD Cameras with FLIR Edge AI Video Analytics
Product Variations
Designed for intelligent monitoring of outdoor sites in the most demanding environments, the Quasar Premium Bullet AI captures critical evidential and forensic video in 5 MP or 4K Ultra HD. This camera integrates FLIR Deep Neural Network (DNN) based Edge AI video analytics to detect and accurately classify humans and vehicles, while object geo-tracking is enabled using FLIR Nexus™.The Quasar Premium Bullet AI camera delivers superior image quality and IR-illumination for exceptional performance at commercial and critical infrastructure sites, remote facilities, or any large area requiring close monitoring.
Compatibility with FLIR accessories as well as the ability to operate more cameras on the same network both contribute to a lower total cost of ownership. The camera also integrates seamlessly with a wide range of video management systems, including United VMS, providing an open, true end-to-end solution for multi-layer security.
Vandal-protected and ruggedized for extreme temperature and high salt environments.
Robust FLIR Edge AI video analytics minimize nuisance alarms and false positives; FLIR Nexus enables PTZ hand-off for object geolocation and tracking.
Low light sensitivity and wide dynamic range provide optimal light balance for high quality images.
Specifications
| Compliance & Certifications | |
|---|---|
| International | CE marked, EN61000-6-3 & EN50130-4, RoHS, RCM, WEEE, BIS, UKCA, ICES-003 |
| USA | UL, FCC Part 15 (subpart B, class A) |
| Cyber Security | |
|---|---|
| AI Video Analytics | Yes |
| Security | Password protection, password policy enforcement, IP address filtering, IEEE 802.1X network access control, digest authentication, CA & self-signed certificates, protect from failed log-in service, firewall |
| Environmental | |
|---|---|
| Humidity | 0%–95% |
| Operating Temperature | IR ON: -40°C to 50°C (-40°F to 122°F) IR OFF: -40°C to 60°C (-40°F to 140°F) Cold Start: -40°C (-40°F) |
| Storage Temperature | -40°C to 60°C (-40°F to 140°F) |
| General | |
|---|---|
| Automatic Electronic Shutter [AES] | 1/3–1/30000 (auto) |
| Compression | Enhanced H.265 main profile + enhanced H.264 Main/high/baseline profile + MJPEG |
| Day_Night Mode | Yes, support for Enhanced Low Light performance |
| Digital Slow Shutter [DSS] | 1/2–1/30 (NTSC) 1/2–1/25 (PAL) |
| Dimensions | 358 × 79 × 89 mm (14.1 × 3.1 × 3.5 in) |
| Enclosure | Indoor/outdoor: IK10 rated vandal IP67 |
| Firmware Upgrade | Flash memory for upgrade of camera firmware over the network |
| Input Voltage | 24 VAC, 12 VDC, PoE+ IEEE 802.3at |
| Power Connection | PoE: RJ45 12 VDC / 24 VAC: terminal block |
| Power Consumption | With Heater OFF and IR ON
12 VDC / 16.6 W 24 VAC / 14.6 W PoE+ / 15 W With Heater ON and IR OFF 12 VDC / 17.9 W 24 VAC / 15.6 W PoE+ / 16.3 W |
| Privacy Zones | Yes |
| Scanning Mode | Progressive |
| Shutter WDR | 130 dB on 15 fps 120 dB on 30 fps |
| Tamper Detection | Yes |
| Unit Weight | 2.15 kg (4.74 lbs) |
| Warranty | According to FLIR RMA Policy and Process Notice document |
| Measurement & Analysis | |
|---|---|
| Automatic Gain Control | Auto |
| PTZ | |
|---|---|
| Pan_Tilt_Spin | 350° / ±7.5° ~ -90° / 350° |
| System Integration | |
|---|---|
| Angle of Illumination | Quasar 4K UHD, 22.3° (Tele) 50° (Wide) FOV, Quasar 5 M QHD, 15° (Tele) 36° (Wide) FOV: 60° Quasar 4K UHD, 50.8° (Tele) 117° (Wide) FOV: 120° Quasar 5 M QHD, 38° (Tele) 106° (Wide) FOV: 140° |
| Bi_directional Audio | 1 Audio line input, G.711 a/µ-law, AAC support + 1 audio line output |
| Distance | Quasar 4K UHD, 22.3° (Tele) 50° (Wide) FOV, Quasar 4K UHD, 50.8° (Tele) 117° (Wide) FOV: 80 m (260 ft.) Quasar 5 M QHD, 15° (Tele) 36° (Wide) FOV, Quasar 5 M QHD, 38° (Tele) 106° (Wide) FOV: 60 m (200 ft.) |
| Ethernet | 10/100, 1000 IEEE 802.3, auto sensing 1 × RJ45 |
| Input | 1 dry alarm contact |
| LED Type | High efficiency SMD |
| Network Protocol | IPv4, HTTP, HTTPS, UPnP, DNS,NTP, RTSP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP, IEEE 802.1X, ONVIF Profile G / T / S |
| Output | 1 relay contact |
| Peak Emission Wavelength [nm] | 850 nm |
| Remote Configuration | Via web browser or supported video management software |
| Supported Web Browser | Firefox, Chrome, Edge |
| Thermal Camera | |
|---|---|
| Image Sensor | Quasar 4K UHD, 22.3° (Tele) 50° (Wide) FOV, Quasar 4K UHD, 50.8° (Tele) 117° (Wide) FOV: 1/1.8-in CMOS Quasar 5 M QHD, 15° (Tele) 36° (Wide) FOV, Quasar 5 M QHD, 38° (Tele) 106° (Wide) FOV: 1/2.8-in CMOS |
| Visible Camera | |
|---|---|
| Backlight Compensation | On/Off |
| Bandwidth | Configurable between 64 Kbps and 20 Mbps |
| Image Sensor | Quasar 4K UHD, 22.3° (Tele) 50° (Wide) FOV, Quasar 4K UHD, 50.8° (Tele) 117° (Wide) FOV: 1/1.8-in CMOS Quasar 5 M QHD, 15° (Tele) 36° (Wide) FOV, Quasar 5 M QHD, 38° (Tele) 106° (Wide) FOV: 1/2.8-in CMOS |
| Lens Type | Quasar 5 M QHD, 38° (Tele) 106° (Wide) FOV: Varifocal 2.8–8 mm, 106°–38° HFOV, f/1.3, D/N, motorized autofocus/auto-iris, P-iris lens Quasar 5 M QHD, 15° (Tele) 36° (Wide) FOV: Varifocal 8–20 mm, 36°–15° HFOV, f/1.5, D/N, motorized autofocus/auto-iris, P-iris lens Quasar 4K UHD, 50.8° (Tele) 117° (Wide) FOV: Varifocal 4–9 mm, 117°–50.8° HFOV, f/1.5, D/N, motorized autofocus/auto-iris, P-iris lens Quasar 4K UHD, 22.3° (Tele) 50° (Wide) FOV: Varifocal 9–20 mm, 50°–22.3° HFOV, f/1.6, D/N, motorized autofocus/auto-iris, P-iris lens |
| Mechanical IR Cut Filter | Yes |
| Noise Reduction | 3D and 2D |
| Sensitivity | Quasar 4K UHD, 22.3° (Tele) 50° (Wide) FOV, Quasar 4K UHD, 50.8° (Tele) 117° (Wide) FOV: 0.04 (color)/0.01 (BW), 0 Lux with IR illuminator ON, measured at 30 IRE Quasar 5 M QHD, 15° (Tele) 36° (Wide) FOV, Quasar 5 M QHD, 38° (Tele) 106° (Wide) FOV: 0.15 (color)/0.01 (BW), 0 Lux with IR illuminator ON, measured at 30 IRE |
| Sensor Resolution | Quasar 4K UHD, 22.3° (Tele) 50° (Wide) FOV, Quasar 4K UHD, 50.8° (Tele) 117° (Wide) FOV: 3840 × 2160 Quasar 5 M QHD, 15° (Tele) 36° (Wide) FOV, Quasar 5 M QHD, 38° (Tele) 106° (Wide) FOV: 2592 × 1944 |
| Signal to Noise Ratio | >50 dB |
| White Balance | Auto/Manual |
| Video & Recording | |
|---|---|
| Maximum Performance | H.264/H.265 30/25 fps @ 5 MP +
H.264/H.265 30/25 fps or MJPEG 15 fps @ 1080p |
| Rate Control | CBR, CVBR, MJPEG |
| Resolution Range | Quasar 4K UHD, 22.3° (Tele) 50° (Wide) FOV, Quasar 4K UHD, 50.8° (Tele) 117° (Wide) FOV: Scalable from D1 to 4K Quasar 5 M QHD, 15° (Tele) 36° (Wide) FOV, Quasar 5 M QHD, 38° (Tele) 106° (Wide) FOV: Scalable from D1 to 5 MP |
| SD Card Recording1 | MicroSDXC up to 2 TB, SD Bus Mode UHS I (SD card not included) |
| Video Motion Detection | Yes |
