Elara™ FB-Series ID
Thermal Analytics Security Camera
Product Variations
The FLIR Elara™ FB-Series ID thermal security camera uses onboard analytics to classify human or vehicular intrusions, making it ideal for perimeter intrusion detection and sterile-zone monitoring. The Elara™ FB-Series ID can also hand off classified intrusions to FLIR PTZ cameras for autonomous tracking of intruders. Easy to set up, Elara™ FB-Series provide reliable detection with low false alarm rates in challenging environments, bad weather, and complete darkness.
Best-in-class intrusion detection with on-board analytics
The Elara FB-Series ID classifies human and vehicle intrusions, and hand-off targets to autonomous PTZ tracking cameras.
The camera is fully certified by third party video management systems, as well as FLIR United VMS.
FLIR's award winning thermal technology is backed by the industry's most extensive warranty.
Specifications
| Environmental | |
|---|---|
| Humidity | 10%-90% relative humidity |
| IP Rating [dust and water ingress] | IP66 |
| Operating Temperature Range | -40°C to 50°C |
| Regulatory | FCC Part 15 (Subpart B, Class A), CE marked, EN55032, EN55024, RoHS, WEEE |
| Storage Temperature Range | -20°C to 70°C |
| General | |
|---|---|
| Detector Type | Long-Life, Uncooled VOx Microbolometer |
| Dimensions [L x W x H] | 285 x 96 x 94 mm/11.1" x 3.8" x 3.7" With sunshield and fully extended mounting arm |
| Effective Resolution | 76,800 pixels |
| Focus Range | Athermalized, focus-free |
| Input Voltage | 12 VDC 24VAC PoE |
| Power Consumption | 12 VDC: 17 W (maximum with heaters) 24VAC : 13 VA (maximum with heaters) 24VDC : 13 W (maximum with heaters) PoE: 13 W |
| Measurement & Analysis | |
|---|---|
| Analytics Features | Region Entrance/Intrusion Detection, Crossover/Fence Trespassing; Auto/Manual Depth Setup, Human and Vehicle Rules, Hand-off target to autonomous PTZ tracking, Tampering Detection |
| Analytics Management | Web-based configuration and management, Masking of analytic detection areas, adjustable sensitivity, automatic responses, remote I/O control |
| System Integration | |
|---|---|
| Ethernet | 10/100 Mbps |
| External Analytics Compatible | Yes |
| Network APIs | Nexus SDK for comprehensive system control and integration; Nexus CGI for http command interfaces; ONVIF Profile S |
| Supported Protocols | IPV4, HTTP, Bonjour, UPnP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP |
| Thermal Camera | |
|---|---|
| Array Format [NTSC] | FB-309 ID, FB-312 ID, FB-324 ID, FB-349 ID, FB-393 ID: 320 x 240 FB-618 ID, FB-632 ID, FB-650 ID, FB-695 ID: 640 x 480 |
| f number | FB-309 ID, FB-312 ID, FB-618 ID, FB-632 ID, FB-650 ID: F1.0 FB-349 ID, FB-393 ID, FB-695 ID: F1.3 |
| Field of view [FOV] | FB-393 ID, 93° FOV, 17 µm: 93° FB-349 ID, 49° FOV, 17 µm: 49° FB-324 ID, 24° FOV, 17 µm: 24° FB-312 ID, 12° FOV, 12 µm: 12° FB-309 ID, 9° FOV, 12 µm: 9° FB-695 ID, 95° FOV, 17 µm: 95° FB-650-ID, 50°FOV, 12 µm: 50° FB-632 ID, 32° FOV, 12 µm: 32° FB-618 ID, 18° FOV, 12 µm: 18° |
| Focal Length | FB-309 ID: 24mm FB-312 ID, FB-618 ID, FB-632 ID, FB-650 ID: 18mm FB-324 ID: 12.8mm FB-349 ID: 6.8mm FB-393 ID, FB-695 ID: 3.7mm |
| Image Uniformity Optimization | Automatic Flat Field Correction (FFC) – Thermal and Temporal triggers |
| Pixel Pitch | FB-309 ID, FB-312 ID, FB-618 ID, FB-632 ID, FB-650 ID: 12u FB-324 ID, FB-349 ID, FB-393 ID, FB-695 ID: 17u |
| Spectral Range | 8 µm to 14 µm |
| Thermal AGC Region of Interest [ROI] | Default, Presets and User Defined for optimal image quality of subjects of interest |
| Thermal Image Settings | Auto AGC, Dynamic Detail Enhancement (DDE), Brightness, Sharpness, Contrast |
| Video Frame Rate | NTSC: 30 Hz |
| Visible Camera | |
|---|---|
| f number | FB-309 ID, FB-312 ID, FB-618 ID, FB-632 ID, FB-650 ID: F1.0 FB-349 ID, FB-393 ID, FB-695 ID: F1.3 |
| Field of view [FOV] | FB-393 ID, 93° FOV, 17 µm: 93° FB-349 ID, 49° FOV, 17 µm: 49° FB-324 ID, 24° FOV, 17 µm: 24° FB-312 ID, 12° FOV, 12 µm: 12° FB-309 ID, 9° FOV, 12 µm: 9° FB-695 ID, 95° FOV, 17 µm: 95° FB-650-ID, 50°FOV, 12 µm: 50° FB-632 ID, 32° FOV, 12 µm: 32° FB-618 ID, 18° FOV, 12 µm: 18° |
| Focal Length | FB-309 ID: 24mm FB-312 ID, FB-618 ID, FB-632 ID, FB-650 ID: 18mm FB-324 ID: 12.8mm FB-349 ID: 6.8mm FB-393 ID, FB-695 ID: 3.7mm |
| Sensitivity | <50mK @ 25c F# 1.0 |
| Spectral Range | 8 µm to 14 µm |
| Video Frame Rate | NTSC: 30 Hz |
| Video & Recording | |
|---|---|
| Composite Video NTSC or PAL | Hybrid system with IP & analog video |
| Digital Video Compression | Two independent channels of H.264 and MJPEG |
| Streaming Resolution PAL_NTSC | FB-309 ID, FB-312 ID, FB-324 ID, FB-349 ID, FB-393 ID: Native: 320x256 FB-618 ID, FB-632 ID, FB-650 ID, FB-695 ID: Native: 640x480 |
